This manual is compatible with all our DeWalt ToughSystem 2.0 Accessories!

*Only the cup holders include x2 of each.
Step-by-Step Assembly Instructions
Before you begin: Ensure all pre-assembled bolts are removed.
Step 1: Determine the desired location and orientation for your accessory on the ToughSystem. If you ordered right-side orientation, select the right side when facing the ToughSystem from the front; for left-side orientation, choose the left side. Larger accessories (e.g., 5in1 level holder) are suitable for the rolling toolbox (bottom compartment), while smaller accessories (e.g., cup holders, cable holders, etc.) can be placed at various locations. Ensure that both parts of the accessory can be assembled and function as intended before proceeding with the drilling process.

Step 2: Optionally, use clear duct tape on the accessory's face to mark drilling holes and edges. If confident, skip steps 3-5 and use the provided part dimensions for hole placement on the toolbox.

Step 3: Remove the tape from the accessory.

Step 4: Apply the tape to the chosen toolbox location, aligning with the marked edges as needed.


Step 6: Drill holes at the marked positions using a 9mm (3/8") drill bit. Secure the accessory using all bolts, lock-nuts, and washers that are provided.

Step 7: Repeat the process for the second part of the accessory.
If you have any questions along the way, don't hesitate to contact us at 3Dbilitytools@gmail.com
